We draw your proposed garage onto a clean, scaled site plan using county GIS data and satellite imagery. Delivered to your inbox in 24 to 48 hours, ready to submit.
Choose your tier — from $89Revised free until your building department accepts it, or your money back
On every garage plan we draw
- Your proposed garage, drawn and dimensioned
- Setback to every property line
- Driveway and access shown
- Existing structures and boundaries
- 11 × 17 sheet
- Drawn by a drafter
- 24 to 48 hours
- All 50 states
Three tiers. Pick what your department asks for.
Every tier includes your garage drawn and dimensioned on the plan. The difference is how much of the rest of the lot comes with it.
Basic
$89
- Property lines
- Lot dimensions
- House roofline, drawn to scale
- North arrow
- Scale
- Parcel ID
- Driveway
- Your proposed garage drawn and dimensioned
Standard
$169
- Everything in Basic
- Setback dimensions labeled on plan
- Sidewalks
- Trees
- Accessory structures
- Fence (if present)
- Swimming pool (if present)
- Measurements between major features
- Vicinity map
Premium
$259
- Everything in Standard
- Impervious surface calculations
- Topographic contour lines
- Easements shown on plan
- Shrubs and paths
- Well and septic system (if present)
- Distances labeled from all existing structures to property lines
- Adds DWG file (CAD format)
Backed by our approval guarantee
Order today and we draft your site plan within 24 to 48 hours. If your reviewer asks for changes, we revise it free, usually within one business day, until your building department accepts it. In the rare case we cannot make it work for your jurisdiction, you get a full refund.
Trusted by contractors
Plans professionals are comfortable submitting.
Deck builder serving Columbus, Dayton and Cincinnati, Ohio.
PermitsGuide may cost a little more than some providers, but the quality is worth every cent. Their plans are clearer and more professional than the alternatives we've used, and every plan we've submitted has been accepted.
About 40 plans now, zero rejections. The DWG in the Premium tier works with my CAD setup.
Carlos T. · Contractor, Austin, TXI run a fencing crew and most of my clients have no survey. Fifteen so far this year and none rejected.
Dwayne F. · Fencing contractorIt comes back overnight, permit goes in the next morning. Keeps my schedule from slipping.
Ashanti M. · Deck builderWhat Your Building Department Checks on a Garage Site Plan
Garages get a closer review than most backyard projects, and the site plan for a garage permit carries a lot of that load. These are the checks your drawing has to answer.
Setbacks. Distances from the garage walls to your side and rear property lines, checked against the accessory-structure setbacks for your zone.
Separation from the house. The gap between a detached garage and your home. Build too close to the house or a lot line and the code starts requiring fire-rated walls, so the reviewer measures this first.
Footprint and placement. The garage's dimensions and square footage, to scale, in its exact spot on the lot. Height and framing details belong on your building plans; the site plan proves the placement.
Driveway and access. How the garage connects to the street. New or widened driveways and curb cuts often trigger their own approvals, and the reviewer looks for them on the site plan.
Lot coverage and easements. Total coverage with the new garage included, plus any easements the structure must avoid.
A garage application with a complete, scaled site plan tends to move through review in one pass. Every garage site plan we deliver includes all of the above, dimensioned from GIS and satellite data. Not sure if you need a permit? See the garage permit rules by state. New to site plans? Start with the complete guide to site plans for permits.
